ARM 架构计算机

Moxa ARM 架构工业计算机支持无线功能，其无风扇结构，体积小，专为小型自动化应用设计。这款计算机能持久运行，提供 5 年硬件保修和支持长达 10年的Moxa 工业 Linux 操作系统，使之成为远程监控和数据采集应用的理想之选。

UC-8410A-T-LX
UC-8410A 系列

Arm-based wireless-enabled wall-mount industrial computer with Cortex-A7 1 GHz dual-core, 1 GB SD card, 512 MB DDR3L, serial ports x 8, DIs x 4, DOs x 4, LANs x 3, wireless enabled, mSATA slots x 1, USB, Debian Arm8, -40 to 75°C operating temperature

Computer

  • CPU

    • Armv7 Cortex-A7 dual-core 1 GHz

  • System Memory Pre-installed

    • 1 GB DDR3L

  • Storage Pre-installed

    • 8 GB eMMC

  • Pre-installed OS

    • Linux Debian 8 (kernel 4.1)

  • Storage Slot

    • SD slots x 1
      mSATA slots x 1, internal mini-PCIe socket
Computer Interface

  • Ethernet Ports

    • Auto-sensing 10/100/1000 Mbps ports (RJ45 connector) x 3

  • USB 2.0

    • USB 2.0 hosts x 2, type-A connectors

  • Digital Input

    • DIs x 4

  • Digital Output

    • DOs x 4

  • Expansion Slots

    • mPCIe slot x 1

  • Cellular Antenna Connector

    • SMA x 2

  • Number of SIMs

    • 1

  • SIM Format

    • Mini

  • Console Port

    • 1 x 4-pin header to DB9 console port

  • Serial Ports

    • RS-232/422/485 ports x 8, software-selectable (RJ45)
Digital Inputs

  • Channel-to-Channel Isolation

    • 3000 VDC

  • Connector

    • Screw-fastened Euroblock terminal

  • Dry Contact

    • On: short to GND
      Off: open

  • Sensor Type

    • Dry contact
      Wet contact (NPN or PNP)

  • Wet Contact (DI to COM)

    • On: 10 to 30 VDC
      Off: 0 to 3 VDC
Digital Outputs

  • Connector

    • Screw-fastened Euroblock terminal

  • Current Rating

    • 200 mA per channel

  • I/O Type

    • Sink

  • Voltage

    • Open-drain to 30 VDC
LED Indicators

  • System

    • Power x 1
      System Ready x 1
      Storage x 1
      Programmable x 10

  • LAN

    • 2 per port (10/100/1000 Mbps)

  • Serial

    • 2 per port (Tx, Rx)
Serial Interface

  • Baudrate

    • 50 bps to 115.2 kbps

  • Flow Control

    • RTS/CTS, XON/XOFF, ADDC® (automatic data direction control) for RS-485, RTS Toggle (RS-232 only)

  • Parity

    • None, Even, Odd, Space, Mark

  • Data Bits

    • 5, 6, 7, 8

  • Stop Bits

    • 1, 1.5, 2
Serial Signals

  • RS-232

    • TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND

  • RS-422

    • Tx+, Tx-, Rx+, Rx-, GND

  • RS-485-2w

    • Data+, Data-, GND

  • RS-485-4w

    • Tx+, Tx-, Rx+, Rx-, GND
Power Parameters

  • Input Voltage

    • 12 to 48 VDC

  • Power Connector

    • Terminal block (for DC models)

  • Power Consumption

    • 19 W (max.)
Physical Characteristics

  • Housing

    • Metal

  • IP Rating

    • IP30

  • Dimensions

    • 200 x 120 x 48.6 mm (7.87 x 4.72 x 1.91 in)

  • Weight

    • 1,000 g (2.21 lb)

  • Installation

    • Wall mounting (standard)
Environmental Limits

  • Operating Temperature

    • -40 to 75°C (-40 to 167°F)

  • Storage Temperature (package included)

    • -40 to 85°C (-40 to 185°F)

  • Ambient Relative Humidity

    • 5 to 95% (non-condensing)
Standards and Certifications

  • EMC

    • EN 55032/24

  • EMI

    • CISPR 32, FCC Part 15B Class A

  • EMS

    • IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV
      IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m
      IEC 61000-4-4 EFT: Power: 0.5 kV; Signal: 0.5 kV
      IEC 61000-4-5 Surge: Power: 0.5 kV; Signal: 1 kV
      IEC 61000-4-6 CS: 3 V
      IEC 61000-4-8 PFMF

  • Safety

    • UL 60950-1

  • Shock

    • IEC 60068-2-27

  • Vibration

    • IEC 60068-2-64
Declaration

  • Green Product

    • RoHS, CRoHS, WEEE
Warranty
